机器型号Model | MS12 | MS16 | MS20 | MS25 | MS32 | MS40 | MS50 | MS63 | |
机槽宽度( mm ) Groove Width | 120 | 160 | 200 | 250 | 320 | 400 | 500 | 630 | |
名义承载深度( mm ) Depth | 120 | 160 | 200 | 250 | 320 | 400 | 500 | 630 | |
额定输送量( m/h ) Rated Capacity | 7-12 | 11-25 | 17-39 | 23-54 | 48-88 | 67-124 | 105-192 | 166-300 | |
最大输送距离(m) Max. Length | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | |
刮板
链条
Chain
|
型号Model | DT | DT | DT | DT(3002T) | 3002T | 3003T | 3003T | 3003T |
许用载荷(KN) Allowable load | 15 | 17 | 26 | 35(45) | 45 | 75 | 100 | 2x75 | |
参考 重量(kg/m) Ref. Weight | 5.5 | 5.62 | 7.2 | 12.2(15.63) | 15.63 | 23.24 | 25.34 | 47.6 | |
运行速度(m/s ) Speed | 0.16-0.32 | 0.16-0.32 | 0.16-0.32 | 0.16-0.32 | 0.2-0.32 | 0.2-0.32 | 0.25-0.32 | 0.25-0.32 |
